Three Arm Flange


CONTACT US Jiangsu Nanyang Chukyo Technology Co., Ltd.

Technical Characteristics

Three arm flange is a component of the drive shaft in the automobile transmission system, the three arms of the flange are evenly spaced around the central opening, creating a symmetrical configuration. This design is often chosen for its ability to distribute loads more evenly compared to flanges with fewer arms. The triangular arrangement enhances the flange's resistance to torsional and shear forces, making it suitable for applications where stability and strength are paramount.

One of the key benefits of the Three-Arm-Flange is its robustness and load-bearing capacity. The three arms work in concert to support the connected components, ensuring that the flange can withstand significant mechanical stresses, pressure differentials, and vibrations. This makes it a preferred choice in industries where pipelines and systems are subject to dynamic forces, such as those encountered in the oil and gas, chemical, or manufacturing sectors.

Installation and alignment are critical considerations in any piping system, and the Three-Arm-Flange design facilitates these processes. The three arms provide distinct points for alignment, simplifying the task of connecting flanged components accurately. This ease of alignment contributes to faster and more efficient assembly, reducing downtime during construction or maintenance activities.


About Us
Jiangsu Nanyang Chukyo Technology Co., Ltd.
Jiangsu Nanyang Chukyo Technology Co., Ltd.
Jiangsu Nanyang Chukyo Technology Co., Ltd., formerly known as Shanghai Jiao Tong University Zhongjing Forging Co., Ltd., was established on October 18, 2017. In April 2019, a new production line was put into operation, and in April 2020, the company completed its relocation from Shanghai to Jiangsu. With the establishment of six production lines, the company leverages the triple brand advantages of Shanghai Jiao Tong University, Jiao Tong Zhongjing, and Nanyang Zhongjing. With the support of advanced high-tech forging technology from Shanghai Jiao Tong University's forging profession, the company has experienced stable development for over thirty years. Currently, the company is a member of the China Forging Association. Custom XC45 Three Arm Flange Forging Parts Factory.
In 2017, the company officially settled in Daitou Town, Liyang City, Jiangsu Province. With an area of 64 acres and a factory space of nearly 16,000 square meters, the company currently employs 200 people. It possesses one 2,500-ton, three 1,600-ton, and one 1,000-ton hot die forging press lines, with mold technicians utilizing advanced CAD/CAM CNC equipment and manufacturing technology. The main products include forged parts for the automotive industry, construction machinery industry, and industrial instrumentation sector, with materials ranging from carbon steel and alloy steel to stainless steel. The annual production capacity of forged parts reaches 20,000 tons. We are XC45 Three Arm Flange Manufacturers and Suppliers in China.
With a strong foundation and expertise in the industry, Jiangsu Nanyang Chukyo Technology Co., Ltd. is committed to providing high-quality forging products that meet the diverse needs of various industries.
Certificate Of Honor
  • ISO14001 2015 Certificate
  • ISO45001 2018 Certificate
  • NYCT IATF16949
  • NYCT ISO9001
  • PED Certificate
  • PED Certificate
